AMT 24BS-1 Base Plate 2 Post Lift


2 Post Hydraulic Lift

Base Plate 2 Post Lift

SKU 2 Post Hydraulic Lift 4 Ton Categories: , , Tags: , ,


  • Base Plate Two Post Lift – Manual single point lock release
  • Dual hydraulic chain-drive cylinders manufactured on high standard, lifting smoothly
  • Screw-up lifting pads with easy to test and locate support points
  • Bending plate type carriage design, safety and reliable
  • External safety lock for easy inspection and maintenance
  • Surface shot blasting process, electrostatic powder spraying strong surface adhesion and durable powder coating
  • It has adopted 120% dynamic load capacity and 150% static load capacity test
  • CE certificated

Technical Data

Model:AMT 24BS-1
Lifting Capacity:4000 Kg
Carriage Height:800 mm
Arm 2 + 2:880-1440 mm / 740-1140 mm
Arm 2 + 3:
Electronic System:
Lifting Time:About 50 sec.
Lowering Time:About 40 sec.
Weight:578 Kg
