Flex Hardware Kit + Full Software Package ( Master Version )

Description:

FLEX Configurator to your workshop. Personalize your FLEX tool according to you needs by choosing the SW packages and accessories that best suit your workload.

Purchase the FLEX HW kit, your first year’s subscription fee is free with purchase.

Full Vehicle List for FLEX

PACKAGE CONTENT

# SKU Code Quantity Description
1 FLK35 1 Cabling kit: FLX3.5 color coded wiring harness
2 FLK42 1 Adapter kit: 6 pcs set of pin adapters to FLX4.2
3 FLX1.1 1 FLEX Base Module
4 FLX1.9 1 FlexBox Module for FLEX
5 FLX2.10 1 Connection cable OBD: FLEX to CAN/Kline RED
6 FLX2.11 1 Connection cable OBD: FLEX to ENet GREEN
7 FLX3.9 1 Connection cable: USB 2.0 AM-BM BLK 1.8m
8 FLX4.9 1 Power Supply adapter 110-240V 14V 5A
9 FLX3.3 1 Connection cable: FlexBox port C to NEC 7F00 XX
10 FLX3.4 1 Connection cable: FlexBox port D to BDM MPC5xx
11 FLX4.1 1 FlexBox port E 40 pins adapter for FLX3.5
12 FLX9.1 1 Flex & FlexBox diagnostic adapter
13 FLX8.10 1 FLEX Branded Box
Category:

Product Details

FLK02 – FLEX Full Kit HW

Use your FLEX to easily tune, reprogram, upgrade or modify the software of most control units directly through the OBD socket of the vehicle. An internet connection gives you access to all the potential that the tool offers you. For advanced and repairing jobs, use the Flexbox module to program your control unit in BDM, Bootloader, JTAG and AUD modes. The device detects eventual connection or communication errors thanks to the concept of its state-of-the -art design. *OBD protocols package will be released in the future.

SW PACKAGES LIST

# SKU Code SW packages Vehicle List for SW Packages
1 FLS0.10M Software Flex Infineon TC17xx – MASTER
2 FLS0.1M Software Flex ECU OBD + Bench – MASTER
3 FLS0.2M Software Flex TCU OBD + Bench – MASTER
4 FLS0.3M Software Flex Motorola MPC5xx – MASTER
5 FLS0.4M Software Flex Nexus MPC5xxx – MASTER
6 FLS0.6M Software Flex Renesas SH7xxxx – MASTER
7 FLS0.7M Software Flex Siemens C165/166/167 – MASTER
8 FLS0.8M Software Flex ST10F2xx – MASTER
9 FLS0.9M Software Flex NEC 76F00xx – MASTER

TECHNICAL DETAILS

Led PC Port
Power Data Error USB 2.0
Power Communication Port
12V 5A/24V 2.5A ISO 15765:2 x CAN ISO 99141-2 & ISO 14230: 2 x K-LINE, 1xL-LINE Ethernet SAE J1850 PWM, VPW SAE J1708
Protections Universal Port
ESD 1kV Over power Over voltage Over temperature Power polarization USB galvanic separation Universal 15 In/Out ports Voltage standard: internal 3.3V, internal 5V, external 1.8 – 5.5V JTAG, BDM, AUD, UART
